| 型号 Model | 规格 Specification | 总长 L（mm） | 扳手尺寸(mm) Wrench size | 适配软管AD Fits To Tubing | 钢管外径及偏差(mm) Steel conduit outer and tolerance |
| YKWS-SSK10 | SSK10 | 30 | 17 | AD10 | φ10±0.5 |
| YKWS-SSK14 | SSK14 | 32 | 24 | AD14 | φ15±0.5 |
| YKWS-SSK17 | SSK17 | 38.5 | 27 | AD17 | φ18±0.5 |
| YKWS-SSK19 | SSK19 | 43 | 27 | AD19 | φ18±0.5 |
| YKWS-SSK21 | SSK21 | 45 | 40 | AD21 | φ25±0.5 |
| YKWS-SSK27 | SSK27 | 54.5 | 45 | AD27 | φ32±0.5 |
| YKWS-SSK27 | SSK27 | 54.5 | 45 | AD27 | φ34±0.5 |
| YKWS-SSK36 | SSK36 | 57 | 55 | AD36 | φ38±0.5 |
| YKWS-SSK36 | SSK36 | 57 | 55 | AD36 | φ42±0.5 |
| YKWS-SSK36 | SSK36 | 58.5 | 65 | AD36 | φ51±0.5 |
| YKWS-SSK45 | SSK45 | 57 | 55 | AD45 | φ38±0.5 |
| YKWS-SSK45 | SSK45 | 57.5 | 55 | AD45 | φ40±0.5 |
| YKWS-SSK45 | SSK45 | 57.5 | 55 | AD45 | φ42±0.5 |
| YKWS-SSK56 | SSK56 | 60 | 65 | AD56 | φ51±0.5 |
| YKWS-SSK56 | SSK56 | 60.5 | 65 | AD56 | φ52±0.5 |
| 注：依据客户安装要求，可提供螺纹长度GL加长以及螺纹定制 Note: According to customer installation requirements, thread length GL extension and thread customization can be provided | |||||
