| 型号 Model | 规格 Specification | 卡口范围(mm) Clamping Range | 适配软管内径 Fits To Tubing | 螺纹长度 GL (mm) | 总高 H (mm) | 扳手尺寸 Wrench Size (mm) |
| YKWS/B-DSJ-M12/φ6 | M12x1.5 | 3~5 | φ6 | 6 | 30.7 | 18/17/14 |
| YKWS/B-DSJ-M16/φ8 | M16x1.5 | 4~7 | φ8 | 7 | 33 | 20/19/18 |
| YKWS/B-DSJ-M18/φ10 | M18x1.5 | 5~8 | φ10 | 7 | 37 | 24/22/20 |
| YKWS/B-DSJ-M20/φ12 | M20x1.5 | 6~11 | φ12 | 7 | 42.4 | 26/26/22 |
| YKWS/B-DSJ-M20/φ15 | M20x1.5 | 6~12 | φ15 | 7 | 43 | 30/28/22 |
| YKWS/B-DSJ-M22/φ15 | M22x1.5 | 8~14 | φ15 | 7 | 43 | 30/28/24 |
| YKWS/B-DSJ-M24/φ15 | M24x1.5 | 8~14 | φ15 | 7 | 43 | 30/28/27 |
| YKWS/B-DSJ-M25/φ15 | M25x1.5 | 10~14 | φ15 | 7 | 44 | 30/28/28 |
| YKWS/B-DSJ-M25/φ20 | M25x1.5 | 13~18 | φ20 | 7 | 47 | 36/34/30 |
| YKWS/B-DSJ-M32/φ20 | M32x1.5 | 13~18 | φ20 | 8 | 47 | 36/34/36 |
| YKWS/B-DSJ-M32/φ25 | M32x1.5 | 15~22 | φ25 | 8 | 51.8 | 45/40/36 |
| YKWS/B-DSJ-M36/φ25 | M36x2 | 15~22 | φ25 | 8 | 51.8 | 45/40/40 |
| YKWS/B-DSJ-M40/φ32 | M40x1.5 | 22~30 | φ32 | 9 | 62 | 55/52/45 |
| YKWS/B-DSJ-M48/φ32 | M48x2 | 22~30 | φ32 | 9 | 65 | 55/52/55 |
| YKWS/B-DSJ-M40/φ38 | M40x1.5 | 22~32 | φ38 | 9 | 67.3 | 60/55/50 |
| YKWS/B-DSJ-M50/φ38 | M50x1.5 | 30~37 | φ38 | 9 | 68.8 | 60/58/55 |
| YKWS/B-DSJ-M50/φ51 | M50x1.5 | 30~38 | φ51 | 9 | 71.7 | 75/75/65 |
| YKWS/B-DSJ-M60/φ51 | M60x2 | 37~44 | φ51 | 10 | 72.7 | 75/75/65 |
| 型号 Model | 规格 Specification | 卡口范围(mm) Clamping Range | 适配软管内径 Fits To Tubing | 螺纹长度 GL (mm) | 总高 H (mm) | 扳手尺寸 Wrench Size (mm) |
| YKWS/B-DSJ-PG7/φ6 | PG7 | 3~5 | φ6 | 6 | 31.7 | 18/17/14 |
| YKWS/B-DSJ-PG9/φ8 | PG9 | 4~7 | φ8 | 7 | 33 | 20/19/17 |
| YKWS/B-DSJ-PG11/φ10 | PG11 | 5~8 | φ10 | 6 | 37 | 24/22/20 |
| YKWS/B-DSJ-PG13.5/φ12 | PG13.5 | 6~11 | φ12 | 7 | 42.4 | 26/26/22 |
| YKWS/B-DSJ-PG16/φ15 | PG16 | 8~14 | φ15 | 7 | 43 | 30/28/24 |
| YKWS/B-DSJ-PG21/φ20 | PG21 | 13~18 | φ20 | 7 | 47 | 36/34/30 |
| YKWS/B-DSJ-PG29/φ25 | PG29 | 18~24 | φ25 | 8 | 56.8 | 45/40/40 |
| YKWS/B-DSJ-PG36/φ32 | PG36 | 22~30 | φ32 | 9 | 65 | 55/52/50 |
| YKWS/B-DSJ-PG42/φ38 | PG42 | 30~37 | φ38 | 9 | 68.8 | 60/58/58 |
| YKWS/B-DSJ-PG48/φ51 | PG48 | 37~44 | φ51 | 10 | 72.7 | 75/75/65 |
| 注：依据客户安装要求，可提供螺纹长度GL加长以及螺纹定制 Note: According to customer installation requirements, thread length GL extension and thread customization can be provided | ||||||
