| 型号 Model | 管内径 Fits To Tubing | 公制 M Thread | 英制 NPT Thread | 美制 G Thread | 螺纹长度 GL (mm) |
| YKWS-DWJ45 | φ12 | M16 | NPT3/8 | G3/8 | 10 |
| YKWS-DWJ45 | φ15 | M20 | NPT1/2 | G1/2 | 10 |
| YKWS-DWJ45 | φ20 | M25 | NPT3/4 | G3/4 | 12 |
| YKWS-DWJ45 | φ25 | M32 | NPT1 | G1 | 12 |
| YKWS-DWJ45 | φ32 | M40 | NPT1-1/4 | G1-1/4 | 14 |
| YKWS-DWJ45 | φ38 | M50 | NPT1-1/2 | G1-1/2 | 15 |
| YKWS-DWJ45 | φ51 | M63 | NPT2 | G2 | 15 |
| YKWS-DWJ45 | φ64 | M75 | NPT2-1/2 | G2-1/2 | 20 |
| YKWS-DWJ45 | φ75 | M85 | NPT3 | G3 | 22 |
| YKWS-DWJ45 | φ100 | M114 | NPT4 | G4 | 28 |
| 型号 Model | 管内径 Fits To Tubing | 公制 M Thread | 英制 NPT Thread | 美制 G Thread | 螺纹长度 GL (mm) |
| YKWS-DWJ90 | φ12 | M16 | NPT3/8 | G3/8 | 10 |
| YKWS-DWJ90 | φ15 | M20 | NPT1/2 | G1/2 | 10 |
| YKWS-DWJ90 | φ20 | M25 | NPT3/4 | G3/4 | 12 |
| YKWS-DWJ90 | φ25 | M32 | NPT1 | G1 | 12 |
| YKWS-DWJ90 | φ32 | M40 | NPT1-1/4 | G1-1/4 | 14 |
| YKWS-DWJ90 | φ38 | M50 | NPT1-1/2 | G1-1/2 | 15 |
| YKWS-DWJ90 | φ51 | M63 | NPT2 | G2 | 15 |
| YKWS-DWJ90 | φ64 | M75 | NPT2-1/2 | G2-1/2 | 20 |
| YKWS-DWJ90 | φ75 | M85 | NPT3 | G3 | 22 |
| YKWS-DWJ90 | φ100 | M114 | NPT4 | G4 | 28 |
| 注：依据客户安装要求，可提供螺纹长度GL加长以及螺纹定制 Note: According to customer installation requirements, thread length GL extension and thread customization can be provided | |||||
