| 型号 Model | 适配软管尺寸 Adapted Hose Size | 英制螺纹 G Thread | 螺纹长度 GL (mm) | 公制螺纹 Metric Thread | 螺纹长度 GL | 德制螺纹 PG Thread | 扳手尺寸 Wrench Size (mm) | |
| 公制 Metric | 英制 inch | |||||||
| YKWS-DPJ6 | φ6 | 3/16" | 3/4" | 7 | M12/M14 | 7 | PG7 | 18/16 |
| YKWS-DPJ8 | φ8 | 5/16" | G3/8" | 7 | M14/M16 | 10 | PG9 | 24/22 |
| YKWS-DPJ10 | φ10 | 1/4" | G3/8" | 8 | M16 | 10 | PG9 | 24/22 |
| YKWS-DPJ12 | φ12(13) | 3/8" | G3/8" | 10 | M16/M18/M20 | 10 | PG11/PG13.5 | 26 |
| YKWS-DPJ15 | φ15(16) | 1/2" | G1/2" | 12 | M20/M22/M24 | 10 | PG13.5/PG16 | 30 |
| YKWS-DPJ20 | φ20(19) | 3/4" | G3/4" | 12 | M25/M27/M30 | 12 | PG21 | 35 |
| YKWS-DPJ25 | φ25 | 1" | G1" | 14 | M32/M33/M36 | 12 | PG29 | 43 |
| YKWS-DPJ32 | φ32 | 1 1/4" | G1 1/4" | 14 | M40/M42/M48 | 14 | PG29 | 52 |
| YKWS-DPJ38 | φ38(40) | 1 1/2" | G1 1/2" | 16 | M43/M50 | 14 | PG36/PG42 | 60 |
| YKWS-DPJ51 | φ51(50) | 2" | G2" | 16 | M60/M63/M64/M72 | 16 | PG48 | 75 |
| YKWS-DPJ64 | φ64(70) | 2 1/2" | G2 1/2" | 24 | M76 | 20 | 89/87 | |
| YKWS-DPJ75 | φ75(80) | 3" | G3" | 25 | M88 | 22 | 102/97 | |
| YKWS-DPJ100 | φ100 | 4" | G4" | 25 | M114 | 28 | 133/128 | |
| YKWS-DPJ125 | φ125 | 5" | G5" | 25 | M140 | 29 | 158 | |
| YKWS-DPJ150 | φ150 | 6" | G6" | 25 | M164 | 29 | 183 | |
