| 规格型号 Article No. | 规格 Specification | 螺纹规格 Thread Size | 螺纹长度 GL(mm) | 卡口范围 Clamping Range(mm) | 结合长度F Length(mm) | 对边 Hexagon size（mm) | |
| YKWS-BW20S | BW20S | M20×1.5 | 10 | 11.8 | 16 | 23 | 24 |
| YKWS-BW20 | BW20 | M20×1.5 | 10 | 14 | 20.8 | 26 | 27 |
| YKWS-BW255 | BW25S | M25×1.5 | 10 | 17.8 | 23.8 | 29 | 30 |
| YKWS-BW251 | BW25 | M25×1.5 | 10 | 19.9 | 27 | 31 | 34 |
| YKWS-BW32S | BW32S | M32×1.5 | 10 | 24 | 30.5 | 32 | 38 |
| YKWS-BW32 | BW32 | M32×1.5 | 10 | 26.2 | 33.5 | 32 | 41 |
| YKWS-BW40 | BW40S | M40×1.5 | 15 | 29.4 | 36 | 34 | 45 |
| YKWS-BW40 | BW40 | M40×1.5 | 15 | 32.4 | 41 | 36 | 50 |
| YKWS-BW50S | BW50S | M50×1.5 | 15 | 38.2 | 46.7 | 40 | 58 |
| YKWS-BW50 | BW50 | M50×1.5 | 15 | 44.1 | 53.1 | 45 | 64 |
| YKWS-BW63S | BW63S | M63×1.5 | 15 | 50.5 | 59 | 48 | 70 |
| YKWS-BW63 | BW63 | M63×1.5 | 15 | 55.5 | 66 | 50 | 77 |
| YKWS-BW75S | BW75S | M75×1.5 | 15 | 62 | 72 | 56 | 85 |
| YKWS-BW75 | BW75 | M75×1.5 | 15 | 68 | 78 | 60 | 91 |
| YKWS-BW90 | BW90 | M90×1.5 | 20 | 80 | 90.5 | 69 | 105 |
