| Metric | Thread Length (Metric) | NPT | Thread Length (NPT) | NPT | Clamping Range | Max(Across Flats | Max（Across Corners） | Protrusion Length | ||
| 16S | M16 | 15 | - | - | - | 2 | 7.4 | 24 | 26.4 | 29.9 |
| 16 | M16 | 15 | 3.2 | 8.7 | 24 | 26.4 | 29.9 | |||
| 20S/16 | M20 | 15 | 1/2” | 19.9 | 3/4” | 2 | 7.4 | 24 | 26.4 | 26 |
| 20S/16 | M20 | 15 | 1/2” | 19.9 | 3/4” | 3.2 | 8.7 | 24 | 26.4 | 26 |
| 20S | M20 | 15 | 1/2” | 19.9 | 3/4” | 6.1 | 11.7 | 24 | 26.4 | 26 |
| 20 | M20 | 15 | 1/2” | 19.9 | 3/4” | 6.5 | 14 | 27 | 29.7 | 27.7 |
| 25 | M25 | 15 | 3/4” | 20.2 | 1” | 11.1 | 20 | 36 | 39.6 | 35.5 |
| 32 | M32 | 15 | 1” | 25 | 1 1/4” | 17 | 26.3 | 41 | 45.1 | 35.1 |
| 40 | M40 | 15 | 1 1/4” | 25.6 | 1 1/2” | 23.5 | 32.2 | 50 | 55 | 35.1 |
| 50S | M50 | 15 | 1 1/2” | 26.1 | 2” | 31 | 38.2 | 55 | 60.5 | 33 |
| 50 | M50 | 15 | 2” | 26.9 | 2 1/2” | 35.6 | 44 | 60 | 66 | 37.3 |
| 63S | M63 | 15 | 2” | 26.9 | 2 1/2” | 41.5 | 49.9 | 70.5 | 77.6 | 33.5 |
| 63 | M63 | 15 | 2 1/2” | 39.9 | 3” | 47.2 | 55.9 | 75 | 82.5 | 36.2 |
| 75S | M75 | 15 | 2 1/2” | 39.9 | 3” | 54 | 61.9 | 84 | 92.4 | 34.1 |
| 75 | M75 | 15 | 3” | 41.5 | 3 1/2” | 61.1 | 67.9 | 84 | 92.4 | 40.9 |
| 90 | M90 | 24 | 3 1/2” | 42.8 | 4” | 66.6 | 79.9 | 108 | 118.8 | 60.3 |
| 100 | M100 | 24 | 4” | 44 | 4” | 76 | 91 | 123 | 135.3 | 57.2 |
| 115 | M115 | 24 | 4” | 44 | 5” | 86 | 97.9 | 133.4 | 146.7 | 67.3 |
| 130 | M130 | 24 | 5” | 46.8 | - | 97 | 114.9 | 152.4 | 167.6 | 74.7 |
