| 型号 Model | 规格 Specification | 卡口范围(mm) Clamping Range | 口径d Calibre(mm) | 主体口径 D(mm) Boby calibre | 螺纹外径 AG (mm) | 主体外径 Body D1(mm) | 螺纹长度 GL (mm) | 总高 H(mm) |
| YKWS/B/Z-TJ8 | TJ8-M14 | 5~7 | 8 | M16x1 | M14x1 | 20 | 9 | 41 |
| YKWS/B/Z-TJ13 | TJ13-M18 | 6~12 | 13 | M20x1 | M18x1 | 24 | 10 | 45 |
| YKWS/B/Z-TJ16 | TJ16-M22 | 11~15 | 16 | M27x1.5 | M22x1.5 | 31.5 | 12 | 52 |
| YKWS/B/Z-TJ19 | TJ19-M27 | 14~18 | 19 | M301.5 | M27x1.5 | 34.5 | 12 | 54 |
| YKWS/B/Z-TJ24 | TJ24-M30 | 17~23 | 24 | M36x1.5 | M30x1.5 | 39.6 | 12 | 56 |
| YKWS/B/Z-TJ28 | TJ28-M36 | 22~27 | 28 | M42x2 | M36x1.5 | 46.5 | 15 | 61 |
| YKWS/B/Z-TJ34 | TJ34-M42 | 26~33 | 34 | M47x2 | M42x2 | 54 | 15 | 64 |
| YKWS/B/Z-TJ42 | TJ42-M52 | 32~41 | 42 | M55x2 | M52x2 | 62 | 15 | 69 |
| YKWS/B/Z-TJ50 | TJ50-M58 | 40~49 | 50 | M62x2 | M58x2 | 68.5 | 15 | 71 |
| YKWS/B/Z-TJ58 | TJ58-M68 | 48~57 | 58 | M71x2 | M68x2 | 77.5 | 20 | 76 |
| 注：依据客户安装要求，可提供螺纹长度GL加长以及螺纹定制 Note: According to customer installation requirements, thread length GL extension and thread customization can be provided | ||||||||
