| Model | M thread | NPT thread | G thread | Cable outer diameter | GL (mm) | H(mm) | |
Outer line | Iner line | ||||||
| YKWS/B-EXI-M16 | M16x1.5 | — | — | 8 | 7~15 | 15 | 68 |
| YKWS/B-EXI-M20 | M20x1.5 | NPT1/2 | G1/2 | 10 | 7~15 | 15 | 68 |
| YKWS/B-EXI-M25 | M25x1.5 | NPT3/4 | G3/4 | 15 | 11~20 | 15 | 68 |
| YKWS/B-EXI-M32 | M32x1.5 | NPT1 | G1 | 20 | 14~20 | 17 | 73 |
| YKWS/B-EXI-M40 | M40x1.5 | NPT1-1/4 | G1-1/4 | 27 | 19~33 | 19 | 80 |
| YKWS/B-EXI-M50 | M50x1.5 | NPT1-1/2 | G1-1/2 | 31 | 24~41 | 19 | 85 |
| YKWS/B-EXI-M63 | M63x1.5 | NPT2 | G2 | 41 | 30~50 | 20 | 93 |
| YKWS/B-EXI-M75 | M75x1.5 | NPT2-1/2 | G2-1/2 | 55 | 38~64 | 21 | 100 |
| YKWS/B-EXI-M85 | M85x1.5 | NPT3S | G3S | 65 | 47~74 | 24 | 103 |
| YKWS/B-EXI-M90 | M90x1.5 | NPT3 | G3 | 65 | 47~7 | 24 | 103 |
| YKWS/B-EXI-M100 | M100x1.5 | NPT4S | G4S | 80 | 57~90 | 26 | 112 |
| YKWS/B-EXI-M110 | M110x1.5 | NPT4 | G4 | 90 | 62~103 | 26 | 112 |
Note: According to customer installation requirements, thread length GL extension and thread customization can be provided | |||||||
