High Strength & Corrosion Resistance
Made of 304/316 stainless steel, resistant to salt spray, acid rain, and chemical corrosion. Ideal for harsh environments like chemical plants and marine applications.
Explosion-Proof & Fire-Resistant
Complies with ATEX/IECEx standards for use in hazardous areas (e.g., oil fields, mines, chemical facilities).
IP68 Waterproof Rating
Fully sealed design provides water and dust resistance, suitable for underwater or high-pressure washdown environments.
High Mechanical Strength
Vibration-resistant and anti-pull design, perfect for mobile equipment or rail transit cable fixation.
| Model | Specification | Clamping Range | AG (mm) | GL (mm) | H (mm) | Wrench Size (mm) |
| YKWS-M8 | M8x1.0 | 2~3.5 | 8 | 6.5 | 15.5 | 12 |
| YKWS-M10 | M10x1.0 | 3~6.5 | 10 | 7 | 19 | 14 |
| YKWS-M12 | M12x1.5 | 3~6.5 | 12 | 7 | 19 | 14 |
| M12x1.5 | 4~8 | 12 | 8 | 21 | 17 | |
| YKWS-M14 | M14x1.5 | 4~8 | 14 | 8 | 21 | 17 |
| YKWS-M16 | M16x1.5 | 3~6.5 | 16 | 8 | 20 | 14/18 |
| M16x1.5 | 4~8 | 16 | 8 | 21 | 17/18 | |
| M16x1.5 | 5~10 | 16 | 8 | 22.5 | 20 | |
| YKWS-M18 | M18x1.5 | 5~10 | 18 | 8 | 22.5 | 20 |
| YKWS-M20 | M20x1.5 | 5~10 | 20 | 8 | 22.5 | 20/22 |
| M20x1.5 | 6~12 | 20 | 8 | 23.5 | 22 | |
| M20x1.5 | 8~14 | 20 | 8 | 23 | 22 | |
| YKWS-M22 | M22x1.5 | 10~14 | 22 | 8 | 23 | 24 |
| M22x1.5 | 10~16 | 22 | 8 | 24.5 | 28 | |
| YKWS-M24 | M24x1.5 | 6~12 | 24 | 8 | 23.5 | 24/27 |
| M24x1.5 | 10~14 | 24 | 8 | 23 | 24/27 | |
| YKWS-M25 | M25x1.5 | 8~14 | 25 | 8 | 23.5 | 24/28 |
| M25x1.5 | 10~16 | 25 | 8 | 24 | 28 | |
| M25x1.5 | 13~18 | 25 | 8 | 26 | 30 | |
| YKWS-M27 | M27x2.0 | 10~16 | 27 | 9 | 24.5 | 28/30 |
| M27x2.0 | 13~18 | 27 | 9 | 26 | 30 | |
| YKWS-M30 | M30x2.0 | 10~16 | 30 | 9 | 24.5 | 28/34 |
| M30x2.0 | 13~18 | 30 | 9 | 26 | 30/34 | |
| YKWS-M32 | M32x1.5 | 13~18 | 32 | 9 | 26 | 30/36 |
| M32x1.5 | 15~22 | 32 | 9 | 28 | 36 | |
| M32x1.5 | 18~25 | 32 | 9 | 33 | 40 | |
| YKWS-M33 | M33x2.0 | 15~22 | 33 | 9 | 33 | 40 |
| YKWS-M36 | M36x2.0 | 15~22 | 36 | 9 | 28 | 36/40 |
| M36x2.0 | 18~25 | 36 | 9 | 33 | 40 | |
| YKWS-M37 | M37x2.0 | 18~25 | 36 | 9 | 33 | 40 |
| YKWS-M40 | M40x1.5 | 18~25 | 40 | 10 | 33 | 40/45 |
| M40x1.5 | 22~30 | 40 | 10 | 35.5 | 45 | |
| M40x1.5 | 22~30 | 40 | 10 | 38.5 | 50 | |
| YKWS-M42 | M42x2.0 | 22~30 | 42 | 10 | 38.5 | 50 |
| YKWS-M47 | M47x2.0 | 25~33 | 48 | 10 | 38.5 | 50/52 |
| YKWS-M48 | M48x2.0 | 25~33 | 48 | 10 | 38.5 | 50/52 |
| YKWS-M50 | M50x2.0 | 22~30 | 50 | 10 | 38.5 | 55 |
| M50x2.0 | 32~38 | 50 | 11 | 40 | 55/58 | |
| YKWS-M54 | M54x2.0 | 32~38 | 50 | 11 | 40 | 58/60 |
| YKWS-M60 | M60x2.0 | 37~44 | 60 | 11 | 41.5 | 65 |
| Model | Specification | Clamping Range | AG (mm) | GL (mm) | H (mm) | Wrench Size (mm) |
| YKWS-M63 | M63x1.5 | 37~44 | 63 | 11 | 41.5 | 65/70 |
| M63x1.5 | 42~53 | 63 | 11 | 44 | 75 | |
| YKWS-M64 | M64x2.0 | 37~44 | 64 | 11 | 41.5 | 65/70 |
| M64x2.0 | 42~53 | 64 | 11 | 44.5 | 75 | |
| YKWS-M72 | M72x2.0 | 37~44 | 72 | 11 | 44.5 | 80 |
| M72x2.0 | 42~52 | 72 | 13 | 44.5 | 80 | |
| M72x2.0 | 55~61 | 72 | 24 | 57 | 86 | |
| YKWS-M75 | M75x2.0 | 37~44 | 75 | 14 | 57 | 86 |
| M75x2.0 | 42~52 | 75 | 13 | 44.5 | 86 | |
| YKWS-M76 | M76x2.0 | 55~61 | 76 | 25 | 57 | 86 |
| YKWS-M80 | M80x2.0 | 55~62 | 80 | 13 | 47 | 86 |
| M80x2.0 | 42~53 | 80 | 13 | 57 | 86 | |
| M80x2.0 | 65~75 | 80 | 13 | 58 | 96 | |
| M80x2.0 | 55~61 | 80 | 25 | 47 | 86 | |
